The GE Fanuc IC693CBK001 serves as a specialized wiring solution for the Series 90-30 PLC platform. This kit facilitates the connection between high-density I/O modules and external field devices. It features right-angle connectors to reduce cable stress in tight enclosure spaces. The assembly provides a secure interface for 32-point modules, replacing traditional straight-connector configurations for better cable management.
Functional Performance and Applications
This cable kit optimizes signal integrity for high-tension industrial circuits. The 24-pin connectors interface directly with the front panel of the PLC module. Engineers utilize these cables when mounting I/O modules to generic terminal blocks. The right-angle design prevents mechanical interference with enclosure doors. The 3-meter length offers flexibility for routing through standard wire ducts.
Technical Specifications and Kit Contents
- Left Side Cable: IC693CBL327
- Right Side Cable: IC693CBL328
- Connector Type: Dual 24-pin Fujitsu style connectors
- Cable Length: 3 Meters (approx. 10 feet)
- Termination: One end 24-pin connector; opposite end stripped and tinned wires
- Current Rating: 1.2 Amps per pin
- Weight: 0.14 kg
Compatible PLC Modules
| Module Model | Description |
| IC693MDL654 | 32-Point 24VDC Input (Positive/Negative Logic) |
| IC693MDL655 | 32-Point 24VDC Input (Fast Response) |
| IC693MDL752 | 32-Point 5/24VDC Output (Negative Logic) |
| IC693MDL753 | 32-Point 12/24VDC Output (Positive Logic) |
