The Vibro-Meter GSI127 (244-127-000-017 A2-B02) functions as a high-performance galvanic isolation interface. This module primarily serves vibration monitoring systems in industrial environments. It provides essential electrical separation between sensing hardware and processing electronics. The unit effectively eliminates ground loop interference. It also ensures clean signal transmission over long distances. Engineers specifically designed this model for integration with Meggitt’s Vibro-Meter product line. This includes compatibility with IPC707 conditioners and TQ series proximity sensors.
Technical Specifications
| Feature | Specification Details |
| Model Number | GSI127 |
| Part Number | 244-127-000-017 A2-B02 |
| Input Voltage | 18 to 30 VDC |
| Frequency Range | 10 Hz to 400 Hz (Signal Rejection) |
| Noise Rejection | ≥ 60 dB |
| Temperature Drift | ≤ 2 mV/°C |
| Output Impedance | 20 Ω (Short-circuit protected) |
| Weight | 0.32 kg |
| Dimensions | 32 x 106 x 130 mm |
Key Functional Characteristics
Signal Integrity and Isolation
The GSI127 module offers superior Power Supply Rejection Ratio (PSRR). It stabilizes signals across a wide frequency spectrum. The floating output design supports a dynamic range of 2 to 20 VDC. This ensures accurate data for critical machinery protection.
Intrinsic Safety and Protection
This unit supports Zone 0 and Zone 2 hazardous area applications. It provides intrinsic safety without requiring separate Zener barriers. The internal architecture protects the sensor-side current up to 22 mA. This reduces overall system complexity and installation costs.
