The Siemens 6SL3120-1TE32-0AA4 serves as a core component for the SINAMICS S120 drive system. This booksize format module provides precise power control for individual industrial motors. It supports both synchronous servo motors and asynchronous induction motors effectively. Consequently, this flexibility makes it ideal for complex motion sequences in packaging and manufacturing. The unit utilizes integrated DC link busbars for efficient energy distribution. Furthermore, the 24V DC bus connection ensures stable internal power for control electronics.
Advanced Connectivity and Safety
This Single Motor Module incorporates three specialized DRIVE-CLiQ interfaces for high-speed data exchange. These ports allow the unit to communicate seamlessly with control units and encoders. For operational security, the module includes a dedicated “Safe Standstill” pulse enable input. It also manages motor brake control to prevent unintended movement during faults. Integrated thermal monitoring supports KTY84-130 and PTC temperature sensors. Therefore, the system protects the motor from overheating during heavy-duty operation.
Technical Capabilities
The module delivers a continuous output current of 45A to meet high torque demands. It operates within a wide input voltage range of 380V to 480V AC. Moreover, the rugged housing includes a comprehensive shield connection system for EMI protection. Multi-color LED indicators provide immediate visual feedback regarding the module status. Dual PE connections further enhance the electrical grounding safety of the installation. This combination of features ensures maximum reliability in electrically noisy environments.
Optimized Machine Design
The compact footprint of the SINAMICS S120 module optimizes space within industrial control cabinets. Its modular architecture allows for quick expansion of multi-axis drive systems. Additionally, the unit features plug-in or screw-type terminals for versatile motor cabling. This design reduces installation time and simplifies maintenance procedures for technical teams. The 6SL3120-1TE32-0AA4 remains a standard for high-performance automation and machine tool applications.
Product Specifications
- Brand: Siemens
- Series: SINAMICS S120
- Model Number: 6SL3120-1TE32-0AA4
- Module Type: Single Motor Module (Booksize)
- Current Rating: 45 Amperes
- Input Voltage: 380V – 480V AC
- Interfaces: 3x DRIVE-CLiQ ports
- Cooling Type: Internal Air Cooling
- Dimensions: 406 mm x 533 mm x 559 mm
- Weight: 26.8 kg
- Manufacturing Origin: Germany
