KJ4001X1-JA1 12P1832X022 Emerson Fisher Rosemount SLS Termination Module

Product Overview

The Emerson KJ4001X1-JA1 12P1832X022 serves as a high-integrity redundant SLS (Safety Logic Solver) terminal block within the DeltaV™ M-series I/O subsystem. This critical interface component facilitates secure field wiring and redundant signal routing for safety-instrumented systems.

Product Description

The KJ4001X1-JA1 12P1832X022 terminal block provides the essential physical termination point for redundant Safety Logic Solvers in the Emerson DeltaV environment. This module supports the dual cable extender architecture, allowing for robust connectivity across distributed control network nodes. By enabling redundant hardware paths, the block ensures that process data remains accessible even if a primary cable or connection fails.

This terminal block features a ruggedized design capable of withstanding extreme thermal stressors ranging from -40°C to +70°C. Furthermore, the unit manages power distribution with a rated capacity of 8 A at 12 VDC, providing high stability against industrial voltage transients. Because the module utilizes high-grade materials, it offers long-term resistance to the corrosive atmospheres often found in chemical processing and oil and gas facilities.

Installation remains efficient due to the compact 16.6 cm footprint, which optimizes space within high-density marshalling cabinets. Although the 12P1832X022 officially entered discontinued status in late 2018, it remains an indispensable legacy component for maintaining the operational integrity of existing DeltaV M-series installations. The block integrates natively with Fisher Rosemount hardware, ensuring that field signals interface correctly with the safety logic layer without signal degradation.

Technical Specifications

• Manufacturer: Emerson (Fisher Rosemount)
• Model Number: KJ4001X1-JA1
• Part Number: 12P1832X022
• Product Series: DeltaV™ M-series I/O
• Module Type: Redundant SLS Terminal Block
• Power Rating: 12 VDC @ 8 A
• Temperature Range: -40°C to +70°C
• Weight: 0.24 kg (Shipping weight)
• Dimensions: 16.6 x 8.8 x 4.5 cm
• System Category: DCS / Safety Instrumented System (SIS)

Engineering Advantages

• Redundant Signal Integrity: Dual cable support eliminates single points of failure in the safety communication bus.
• Industrial Durability: The hardened chassis operates reliably in unconditioned environments and extreme climates.
• Space-Saving Design: The slim profile allows for increased I/O density in standard DeltaV rack configurations.
• Simplified Maintenance: Passive terminal architecture allows for rapid wiring verification and module replacement without disturbing adjacent field loops.

FAQs

• Which system is the KJ4001X1-JA1 compatible with?
• This terminal block is specifically designed for the Emerson DeltaV M-series I/O subsystem and Fisher Rosemount safety logic solvers.
• Does this module support high-temperature environments?
• Yes, the KJ4001X1-JA1 operates within a broad temperature range of -40°C to +70°C, making it suitable for unheated industrial enclosures.
• What is the difference between the model number and the part number?
• KJ4001X1-JA1 is the model designation used for identification in the DeltaV software, while 12P1832X022 is the specific hardware part number.
