Allen-Bradley 80026-096-01-R PowerFlex DC Converter Module

Allen-Bradley 80026-096-01-R DC Converter

Configured for power regulation in industrial control platforms, the Allen-Bradley 80026-096-01-R provides direct electrical conversion and stabilization. This module ensures that peripheral devices receive consistent voltage levels, which is a requirement for maintaining uptime in [link:Automated Systems].

Suffix Breakdown and Model Matrix

• 80026: Identifies the base PowerFlex architecture series.
• 096: Specifies the internal design iteration and power rating class.
• 01-R: Indicates the output configuration and revision level.

Electrical Performance and Specifications

Industrial Control Characteristics and Power Regulation

The hardware maintains consistent backplane bus communication velocity when integrated into larger PLC architectures. It utilizes high-density internal circuitry to achieve I/O density scaling, allowing for efficient placement within crowded control cabinets. The unit supports firmware flash compatibility, which enables field upgrades to internal logic parameters. Deterministic network performance remains uncompromised as the device filters electrical noise, supporting robust operation within EtherNet/IP deterministic networks. The module also features an internal heat sink dissipation profile optimized for high-temperature environments. For detailed wiring diagrams, refer to the [link:Official Rockwell Automation Documentation].

Frequently Asked Questions

Q: Can this unit handle sudden input voltage transients?

A: The converter includes integrated surge protection to mitigate standard industrial line transients. However, external surge suppression should be installed if the DC supply line is subject to high-energy inductive switching or lightning risks.

Q: Is this power regulation module capable of parallel output operation for increased current?

A: No, parallel connection of multiple units to increase output current is not supported, as this can cause instability in the internal feedback control loops. Each power rail should be isolated.

Field Installation Guidelines

1. Physical Mounting: Install the unit on a standard DIN-rail or flat panel using the integrated mounting brackets. Orient the unit vertically to maximize airflow through the convective heat sink fins.
2. Wiring Constraints: Use shielded copper cabling for both input and output connections. Keep DC output leads as short as possible to minimize inductive voltage drop and high-frequency noise pickup.
3. Shielding: Terminate the cable shield at the designated chassis ground point only at the power source end to prevent ground loops.
4. Thermal Management: Ensure a minimum 5 cm clearance gap above and below the device to prevent thermal derating under maximum load conditions.
