Primary Technical Specifications
- Product Line: S600 I/O System
- Model Designation: AI620
- Order Number: 3BHT300005R1
- Channel Count: 16 Analog Inputs
- Signal Resolution: 12-bit
- Voltage Range: -10 V to +10 V DC
- Isolation Voltage: 50 V
- Operational Temperature: -25°C to +85°C
- Physical Mass: 1.24 kg
- Module Dimensions: 4 x 26.1 x 27 cm
Operational Precision and Thermal Stability
The AI620 module utilizes 12-bit resolution to ensure fine-grain signal accuracy. This precision helps operators maintain tight control over temperature, pressure, and flow rates. Consequently, the hardware reduces measurement drift during long-term industrial operations.
Additionally, the robust internal components allow for a wide operating temperature range. The module performs reliably in extreme environments from -25°C up to +85°C. This thermal resilience makes it ideal for remote field enclosures or hot process zones.
Installation and Protection Features
The module features an integrated 50 V isolation barrier to safeguard the internal logic. This protection prevents common-mode noise and voltage surges from damaging the central control system. Therefore, the unit maintains high signal integrity in electrically noisy environments.
Moreover, the Swedish-engineered design focuses on ease of maintenance and rapid deployment. The compact 4 cm width allows for efficient side-by-side mounting on standard racks. Engineers can integrate the AI620 into existing DCS architectures with minimal configuration effort.
