ABB DI830 3BSE013210R1 Digital Input Module

Primary Technical Specifications

• Product Family: S800 I/O
• Model Designation: DI830
• Order Number: 3BSE013210R1
• Input Channels: 16 Channels (organized in groups)
• Signal Type: 24 V DC Digital Input
• Module Weight: 0.18 kg
• Physical Dimensions: 4.5 x 10.5 x 12 cm
• Operating Temperature: -25°C to +60°C
• Manufacturing Origin: Sweden
• System Category: DCS / Process Automation

Signal Integration and Connectivity

The DI830 module integrates seamlessly into the Advant OCS and 800xA control architectures. It communicates with the host controller through a dedicated cluster bus or fieldbus interface. Moreover, the unit supports hot-swap functionality when paired with the correct terminal base.

Additionally, the input circuitry features advanced filtering to eliminate electrical debounce and noise. This filtering ensures that only valid process signals trigger event logs. Therefore, the module provides a reliable data foundation for high-speed manufacturing and power generation applications.

Environmental Design and Reliability

ABB utilizes rugged internal components to ensure a long service life in demanding factory zones. The module operates efficiently across a broad temperature range without losing timing accuracy. Furthermore, the slim 45mm housing design maximizes rail space in congested electrical cabinets.

The 3BSE013210R1 also features front-facing LED indicators for rapid visual diagnostics. These indicators show the real-time status of each input and the overall health of the module. This feature simplifies maintenance tasks and reduces the time required for field troubleshooting.
