2711P-T12W22D9P Allen-Bradley PanelView Plus 7 Performance Touchscreen

Product Description

The Allen-Bradley 2711P-T12W22D9P functions as a premier human-machine interface within the PanelView Plus 7 Performance series. This terminal provides comprehensive visualization and control for complex automation systems, allowing operators to monitor real-time data and manage machine parameters through an intuitive 12.1-inch widescreen interface.

Technical Specifications

Functional Description

This HMI terminal streamlines the interaction between plant personnel and Logix-based controllers. It utilizes a powerful 1 GHz processor to render high-resolution graphics and handle dense data tags without latency. The widescreen format offers significantly more workspace for complex process screens compared to standard 4:3 displays. Furthermore, the integrated 2 GB non-volatile memory secures application files and data logs locally, ensuring that critical information remains accessible even after power cycles. The resistive touch surface permits operation with fingers, gloved hands, or styluses, making it adaptable to various industrial workstation requirements.

Engineering Advantages

• High-Availability Networking: Dual Ethernet ports facilitate seamless connection to Device Level Ring (DLR) topologies. This configuration ensures that communication persists even if a single physical link fails, which maximizes system uptime.
• Controller Integration: The hardware features native optimization for Premier Integration with Studio 5000 and Logix controllers. This synergy allows engineers to reuse controller tags directly, reducing configuration errors and commissioning time.
• Environmental Durability: An IP66-rated front bezel effectively seals internal electronics against pressurized water jets and airborne contaminants. This ruggedized construction supports reliable operation in demanding food and beverage or chemical processing facilities.
• Superior Visual Clarity: The LED-backlit WVGA screen provides sharp contrast and wide viewing angles. Consequently, operators can accurately assess process alarms and trends from various positions on the factory floor.
• Energy Efficient Operation: Despite its high processing power, the unit maintains a maximum power consumption of only 50W. This thermal efficiency reduces heat buildup inside control cabinets and extends the lifespan of internal components.

FAQs

• Does this model support Device Level Ring (DLR)?

  Yes, the dual Ethernet ports allow this terminal to function as a node in a DLR network, providing media redundancy for critical control loops.

• Can I run Windows applications on the 2711P-T12W22D9P?

  This Performance terminal runs on a closed Windows CE environment optimized specifically for FactoryTalk View Machine Edition (ME), ensuring a secure and stable operator interface.

• What is the recommended power supply for this unit?

  The unit requires a 24V DC power source. We recommend using a Class 2 power supply to ensure compliance with industrial safety standards and to protect the sensitive internal circuitry from voltage spikes.

• Is the 12.1-inch screen readable in dark environments?

  Yes, the high-quality LED backlight provides adjustable brightness, ensuring the display remains clearly visible in both low-light areas and well-lit production halls.
