2711P-RP1X Allen Bradley PanelView Plus CE Replacement Logic Unit

Product Description

The Allen Bradley 2711P-RP1X serves as the primary processing engine for modular PanelView Plus and PanelView Plus CE operator interface terminals. This unit replaces damaged or underperforming logic assemblies behind the display matrix to restore complete human-machine interface functionality.

Technical Profile and Specifications

• Product Series: PanelView Plus / PanelView Plus CE Platform
• Component Type: Core Logic Module Assembly
• Operating System Environment: Windows CE
• Application Compatibility: FactoryTalk View Machine Edition (ME)
• Onboard Flash Memory: 128 MB
• System RAM: 128 MB
• Built-In Interfaces: One RJ45 10/100 Ethernet Port, One RS-232 Serial Port, Two USB Ports
• Expansion Storage Options: CompactFlash Card Slot
• Input Voltage Requirement: 24 Volts DC (drawn from connected display or base)
• Physical Dimension Profile: 20.8 cm x 14.0 cm x 4.5 cm
• Total Net Weight: 0.66 kg (1.45 lbs)
• Customs Tariff HS Code: 8537101190

Operational Role and Core Integration

This core processing board runs your local human-machine interface configuration. Specifically, the processor handles complex graphic rendering, local alarm logging, and real-time recipe management. Because the device separates completely from the front bezel, users can upgrade system performance without replacing the expensive display glass.

Additionally, the hardware features integrated commercial software components. The system natively supports PDF viewers and Microsoft Office file readers to display technical documents right on the factory floor. Meanwhile, third-party developers can utilize the internal .NET compact framework to deploy specialized data-collection routines.

Network Communication and Maintenance Protocol

This logic module connects seamlessly to plant-wide control networks using its dual onboard communication options. The 10/100 Base-T Ethernet port handles high-speed telemetry links to modern ControlLogix and CompactLogix automation arrays. Simultaneously, the point-to-point RS-232 serial interface accommodates legacy DH-485 or DF1 industrial networks.

Maintenance personnel install this module directly onto the rear mounting plane of 700, 1000, 1250, and 1500 flat-panel displays. The design uses standard retention screws to ensure stable mechanical fastening under continuous equipment vibration. Ultimately, using this modular replacement approach minimizes capital expenditure during screen upgrades or processor hardware refreshes.
