Yokogawa NFDV561-P00 S2 Digital Output Module

The Yokogawa NFDV561-P00 S2 operates as a high-density digital output solution for modern Distributed Control Systems (DCS). This module features 64 discrete channels to manage a wide array of field devices. It primarily controls solenoid valves, motor starters, and auxiliary relay circuits. Each channel supports a current sink configuration to ensure robust switching performance. By consolidating 64 points into one module, it significantly reduces the required cabinet footprint. Consequently, engineers can design more efficient and compact control enclosures for large-scale plants.

Technical Performance Specifications

Key Industrial Advantages

• Maximum Port Density: Manages 64 independent outputs within a single narrow-slot module.
• Efficient Heat Management: Low leakage current ensures cool operation in dense cabinets.
• Hot-Swap Capability: Allows for module replacement while the system remains energized.
• DCS Native Integration: Connects directly to Yokogawa FIO baseplates for immediate communication.
• Precision Performance: Delivers fast response times for high-speed industrial switching requirements.

Reliable Switching and Signal Integrity

This module utilizes a 24V DC field power supply to drive industrial loads effectively. It maintains strict electrical tolerances to ensure reliable operation in volatile process environments. For instance, the hardware limits the “ON” state voltage drop to 2V DC. Meanwhile, the leakage current during the “OFF” state remains below 0.1mA. These technical safeguards prevent accidental device triggering and minimize heat generation. Furthermore, the unit integrates seamlessly with the CENTUM VP platform for real-time logic execution. Trust this module to deliver stable discrete control in power and chemical facilities.
