Honeywell Experion DCS TC-PPD011 Power Support Extension Card

Product Overview

The Honeywell TC-PPD011 (51309241-125) functions as a dedicated hardware battery extension module within the Experion LS control system family. This expansion hardware directly secures system data integrity by maintaining auxiliary power to critical processor components.

Continuous processing facilities depend on this module to safeguard their system configuration profiles. Consequently, the device prevents catastrophic system downtime and data corruption during unexpected facility blackout events.

Technical Architecture and Power Allocation

This module incorporates a high energy density lithium-ion storage cells engineered for extended standby lifecycles. The internal charging circuitry draws power directly from the system backplane to maintain the battery at an optimal readiness state.

During active operation, the module exhibits highly efficient power consumption profiles across separate voltage rails. Specifically, the card draws 0.036 Amps on the 24 VDC rail and 0.112 Amps on the 5 VDC rail.

Industrial Applications

• Continuous chemical processing plants and petrochemical distillation units

• Distributed power generation control rooms and steam turbine monitoring

• Water and wastewater treatment facility remote telemetry stations

Technical Parameter Specifications

• Brand: Honeywell

• Model Number: TC-PPD011

• Part Number: 51309241-125

• Product Range: Experion LS DCS

• Country of Manufacture: USA

• Unit Weight: 0.5 kg

• Physical Dimensions: 17.8 cm x 10.0 cm x 5.2 cm

• Operating Temperature Limit: -20 to 60 Celsius

• Input Rail Drawing One: 0.036 Amps at 24 VDC

• Input Rail Drawing Two: 0.112 Amps at 5 VDC

• Cell Core Chemistry: Industrial Lithium-Ion

• Harmonized Tariff Code: 8537101190
