The GE DS200SLCCG1ADC functions as a high-performance LAN interface for the Mark V Speedtronic turbine control system. This card enables robust network connectivity across diverse drive types and exciters. It plays a vital role in maintaining legacy gas, steam, and wind turbine installations.
Technical Specifications
| Property | Details |
| Brand | General Electric (GE) |
| Model Number | DS200SLCCG1ADC |
| Series | Mark V Speedtronic |
| Module Type | LAN Communications Card |
| Network Protocols | DLAN and ARCNET |
| Weight | 0.38 kg |
| Dimensions | 24.5 x 18.5 x 8 cm |
| Manufacturing Origin | USA |
Core Functional Architecture
This communications card integrates a dedicated LAN Control Processor (LCP) to manage data traffic. The LCP effectively filters incoming signals to protect the drive from electrical interference. Additionally, dual-ported RAM facilitates rapid data exchange between the LCP and the primary drive control board.
The module features two removable EPROM sockets for storing essential firmware and program code. Users can interface directly with the board using an attachable alphanumeric keypad programmer. This tool allows for real-time monitoring of system diagnostics and local configuration adjustments.
Hardware Integrity and Protection
The DS200SLCCG1ADC utilizes a sophisticated array of resistors, capacitors, and integrated circuits for voltage suppression. These components ensure the card remains stable during transient power events. Furthermore, the board architecture represents the final development phase of the Mark V LAN series.
GE engineers designed this version with specific coating styles to resist industrial contaminants. The board revision level “ADC” indicates significant improvements over earlier iterations. These updates enhance the overall fault tolerance and communication speed of the Speedtronic network.
