Essential Technical Specifications
- Manufacturer: Allen-Bradley / Rockwell Automation
- Model Number: 1769-IF4XOF2
- Module Type: Analog Combination Input/Output
- Input Channels: 4 Points (Single-ended or Differential)
- Output Channels: 2 Points (Voltage or Current)
- Resolution: 8-bit Successive Approximation
- Voltage Ranges: 0–10V DC (10.5V max)
- Current Ranges: 0–20mA (21mA max)
- Input Accuracy: ±0.7% (Voltage), ±0.6% (Current)
- Output Load: >1kΩ (Voltage), <300Ω (Current)
- Backplane Current: 120mA @ 5V DC; 160mA @ 24V DC
- Dimensions: 35 x 118 x 87 mm
- Weight: 0.29 kg
Advanced Signal Conversion and Diagnostics
The 1769-IF4XOF2 utilizes a successive approximation ADC for rapid signal conversion. It translates physical values into 8-bit raw data for the controller CPU. While designed for general-purpose use, the module maintains steady thermal stability. It features a minimal thermal drift of only ±0.006% per degree Celsius. Moreover, the 60dB common-mode rejection ratio ensures high noise immunity in industrial environments.
The output section employs a resistor-string DAC for consistent signal generation. It delivers fast response times under 0.3ms for typical resistive loads. For protection, the module requires an external power supply to drive field-side loops. This separation prevents electrical interference between the field devices and the backplane logic. Furthermore, the front panel includes an LED indicator to confirm active module status.
Installation and System Compatibility
Integration remains straightforward within the 1769 Compact I/O architecture. The module supports a maximum of eight units per power supply bank. Furthermore, it carries CE and c-UL certifications for global industrial compliance. This ensures the unit meets rigorous safety and electromagnetic standards.
Technicians should verify load resistance before connecting field devices to the outputs. Voltage outputs require at least 1kΩ of resistance to maintain accuracy. Conversely, current outputs must operate with loads under 300Ω. Following these guidelines ensures the 1769-IF4XOF2 provides stable and long-term performance. Finally, the brand-new condition of this unit guarantees original factory specifications for your project.
