Product Summary
The Honeywell 51305508-200 serves as a high-performance automation interface and extender paddle board designed for the Experion PKS and TDC 3000 Distributed Control Systems (DCS). It facilitates reliable signal routing and system expansion in complex industrial network architectures.
Product Overview
The 51305508-200 (51305508200) functions as an essential automation module and extender paddle board within the Honeywell Experion PKS and legacy TDC 3000 environments. This module specifically supports the XLCNE2 communication infrastructure, acting as a critical bridge for data transmission and signal extension across the DCS backplane. Industrial facilities in sectors such as oil and gas, petrochemical refining, and large-scale power generation rely on this board to maintain high-speed deterministic communication between controllers and field hardware. By utilizing military-grade circuitry, the module preserves signal integrity even when subjected to significant electromagnetic interference (EMI) or mechanical vibration. Consequently, the board ensures the continuous availability of process data, which is vital for preventing unplanned plant shutdowns and maintaining rigorous safety standards in hazardous areas.
Technical Architecture and Functional Scope
The hardware design of the 51305508-200 emphasizes low-latency signal processing and adaptive power management. The board manages local power distribution to ensure that attached components receive stable voltage levels, thereby extending the MTBF (Mean Time Between Failures) of the entire automation rack. Moreover, the integrated diagnostic indicators allow maintenance personnel to verify link status and board health at a glance. Because the board supports Ethernet router communication services, it integrates seamlessly into modern networked control strategies while maintaining backwards compatibility with traditional TDC 3000 PC board configurations. This versatility allows engineers to modernize specific segments of their control system without requiring a complete hardware overhaul. Furthermore, the plug-and-play architecture simplifies hot-swapping procedures, ensuring that system expansions or repairs occur with minimal disruption to the active control loop.
Technical Specifications
- Model: 51305508-200
- Brand: Honeywell
- System Environment: Experion PKS / TDC 3000
- Module Type: Automation Module / XLCNE2 Extender Paddle Board
- Communication Protocol: Ethernet / Proprietary DCS Backplane
- Application: Distributed Control System (DCS) Expansion
- Input Voltage: System Sourced (24 VDC Nominal)
- Operating Temperature: 0 to 60 deg C
- Weight: 0.2 kg
- Dimensions: 2 x 13.5 x 23.7 cm
- Origin: USA
- HS Code: 8537101190
