2094-BC02-M02-M Allen-Bradley 460V 15kW Converter 6.6kW Inverter Module

Integrated Power Conversion and Motion Control

The 2094-BC02-M02-M functions as the primary entry point for power within a Kinetix 6000 series drive rail. It efficiently converts a 360-480V AC three-phase input into a regulated DC bus voltage to supply power to adjacent follower axial modules. By integrating a 23A converter with a 14.6A inverter, the module reduces the physical footprint of the control cabinet. This dual-purpose architecture allows the unit to manage both the main power distribution and the precision control of an individual servo motor simultaneously.

Advanced Safety and Monitoring Features

This module prioritizes operational safety by incorporating embedded Safe Torque-Off (STO) functionality. This feature allows the drive to disable motor torque without removing power from the entire system, facilitating faster restarts after safety interventions. Furthermore, the 2094-BC02-M02-M supports advanced safety configurations such as Safe Speed Monitoring and Safe Maximum Speed. These capabilities ensure that the machinery remains within defined velocity limits, protecting both the hardware and the operators during maintenance or manual setup tasks.

Electrical Protection and Efficiency

To safeguard against catastrophic electrical failure, the module features robust short-circuit protection. When utilized with recommended branch circuit components—such as the Bussmann FNQ-R-10 for control circuits—the module achieves a high Short Circuit Current Rating (SCCR) of up to 200,000A. The hardware optimizes thermal management by maintaining low heat dissipation, even under heavy loads. Integrated diagnostics provide constant feedback regarding the health of the DC bus and the inverter stage, allowing for proactive maintenance and reduced system downtime.
