Core Technical Specifications
| Feature | Specification Details |
| Model Number | BMENOC0301 |
| Module Type | Ethernet Communication Module |
| Port Configuration | 3 Ports (2 x RJ45, 1 x X-bus) |
| Transmission Rate | 10/100 Mbps Auto-sensing |
| Protocols | EtherNet/IP and Modbus TCP |
| Redundancy | RSTP (Rapid Spanning Tree Protocol) |
| Power Consumption | 555 mA at 3.3 V DC |
| Weight | 0.2 kg |
Advanced Connectivity and Integration
This module provides two external RJ45 ports to support flexible industrial network topologies. Users can implement reliable ring configurations to ensure continuous operation during cable failures. Additionally, the integrated X-bus connection links the module directly to the M580 backplane. The BMENOC0301 also features an embedded web server for remote diagnostics. This tool allows technicians to monitor system health through a standard web browser. Consequently, maintenance teams can identify network issues without specialized software tools.
Industrial Applications and Reliability
The BMENOC0301 excels in demanding sectors like wastewater treatment and power generation. Its rugged French design ensures stability in high-vibration and electrically noisy environments. The module manages heavy data traffic between HMIs, SCADA systems, and distributed I/O. Furthermore, it streamlines hardware installation by drawing power directly from the rack. This efficiency reduces wiring complexity within the control cabinet. The module remains an essential component for engineers building future-ready, Ethernet-based automation systems.
