IC693ACC310 GE Fanuc Empty Baseplate Slot Protective Filler Module

Brief Product Description

The GE Fanuc IC693ACC310 serves as a mechanical blanking plate that covers empty channels on Series 90-30 programmable logic controller baseplates. This passive component preserves intended cooling dynamics and seals open backplane connectors against abrasive industrial contaminants.

Product Overview

The GE Fanuc IC693ACC310 functions as a non-intelligent hardware slot cover for the Series 90-30 programmable logic controller (PLC) lineup. This module fulfills a critical maintenance role within industrial automation systems because it physically seals unpopulated expansion or I/O channels on a standard baseplate rack. In demanding environments such as petrochemical plants, municipal water facilities, and automated assembly operations, unpopulated backplane slots present structural and operational risks. Therefore, implementing this module blocks airborne conductive particulates, moisture, and debris from settling onto exposed backplane pins, which effectively eliminates the risk of internal short circuits.

In addition to contamination shielding, this plastic chassis block actively regulates thermal conditions inside the control enclosure. Because empty spaces disrupt the engineered convective airflow within a PLC rack, installing the module forces air directly across active processing and power components. Consequently, this thermodynamic containment maximizes the operational lifespan of surrounding modules and prevents localized overheating. While legacy hardware production officially ceased on December 31, 2018, maintaining warehouse reserves of this component ensures structural compliance and protects your operational system footprint during structural control modifications.

Architectural Layout and Physical Implementation

This mechanical dummy block contains no electrical circuitry, onboard logic components, or power routing traces. Instead, it mounts directly onto any standard Series 90-30 baseplate slot by utilizing the identical mechanical latching mechanics found on functional I/O units, which guarantees a secure fit even when exposed to continuous heavy machinery vibration.

The rugged outer casing consists of an industrial-grade thermoplastic polymer selected specifically for its structural stability under thermal stress and resistance to common chemical cleaners. Because this unit lacks field wiring terminal blocks, backplane connector pins, or diagnostic LEDs, it draws absolutely no internal current from the 5 VDC or 24 VDC rack power supplies. As a result, engineers can install or extract this protective frame at any time without disrupting active PLC applications or cycling power to the main CPU node.

Technical Performance Manifest

• Model: IC693ACC310
• Brand: GE Fanuc (Emerson Automation Solutions)
• System Series: Series 90-30 PLC
• Component Type: Slot Filler Module / Blanking Plate
• Country of Origin: USA
• Electrical Connectivity: None (Mechanical isolation frame)
• Internal Power Consumption: 0 mA (Passive component)
• Physical Weight: 0.12 kg
• Outer Dimensions: 3.5 cm x 13.0 cm x 13.5 cm
• Operating Temperature Range: 0 to 60 deg Celsius
• Storage Temperature Range: -40 to 85 deg Celsius
• Relative Humidity Limits: 5 to 95 percent non-condensing
• HS Harmonized Code: 8538909100 (Parts for industrial control apparatus)
