HIMA Z7138 Cable Plug

The HIMA Z7138 serves as a specialized Ethernet communication interface within the HIQuad X safety system architecture. This cable plug enables high-speed data exchange across industrial networks, facilitating seamless connectivity between decentralized control components. It specifically supports data transfer rates reaching 100 Mbps, which ensures low-latency communication essential for real-time safety applications and complex automation tasks.

Engineered for durability, the Z7138 operates on a standard 24 V DC power framework. Its design focuses on electromagnetic compatibility (EMC) to maintain signal integrity in high-interference environments. The module utilizes advanced filtering technology to mitigate electrical noise, providing a stable link for critical DCS and Ethernet router services.

Key Technical Characteristics

• System Compatibility: Exclusively designed for the HIMA HIQuad X safety platform.
• Communication Rate: Supports industrial Ethernet speeds up to 100 Mbit/s.
• Power Requirements: Optimized for 24 V DC industrial power supplies.
• Form Factor: Compact housing measuring 2cm x 6cm x 10.3cm for high-density rail mounting.
• Safety Compliance: Fully certified under CE and UL standards for hazardous industrial locations.
• Physical Weight: Ultra-lightweight 0.08kg construction reduces mechanical stress on connectors.

Industrial Applications

The Z7138 module primarily functions within Distributed Control Systems (DCS) and safety-instrumented systems (SIS). It provides the physical and logical link for Ethernet-based safety protocols. Engineers typically deploy this cable plug in chemical processing plants, power generation facilities, and large-scale robotic assembly lines. Its “active” status ensures long-term availability for both new installations and the maintenance of existing HIQuad X infrastructure.

Product Specifications
