HESG216850M1/D 316GW61 ABB DCS Ethernet Router Control Board

Brief Product Description

The ABB HESG216850M1/D 316GW61 is a specialized Procontic b series control board designed for DCS environments, featuring integrated Ethernet routing and high-density I/O processing for complex industrial automation.

Product Overview

The HESG216850M1/D 316GW61 serves as a foundational component within the ABB Procontic b ecosystem, specifically functioning as a high-performance control unit for Distributed Control Systems (DCS). This board facilitates critical logic execution and data management across industrial networks. By integrating advanced communication services, including Ethernet routing, the module ensures that data flows seamlessly between field devices and supervisory levels. Consequently, it provides the reliability necessary for managing sophisticated automation sequences in high-stakes environments such as power plants and manufacturing facilities.

Key Technical Characteristics

Engineered to maintain precision under rigorous operational demands, the HESG216850M1/D 316GW61 incorporates several advanced features:

• Advanced Processing Logic: The unit handles high-frequency signal processing, supporting complex control loops with minimal latency.
• High-Density I/O Interface: With 40 dedicated input channels and 24 output channels, the board offers extensive connectivity for sensors and actuators.
• Robust Memory Management: A 1MB onboard memory capacity allows for the local storage of extensive instruction sets and historical operational data.
• Network Integration: The board supports multi-protocol communication, including MODBUS and CANopen, ensuring compatibility with diverse hardware architectures.
• Industrial Protection: Housed in an IP65-rated enclosure, the module resists dust and moisture ingress, which is vital for maintaining uptime in unconditioned industrial spaces.
• Thermal Resilience: The hardware operates effectively across a wide temperature spectrum from -20°C up to +70°C.

Technical Specifications

• Manufacturer: ABB
• Model Number: HESG216850M1/D
• Part Identification: 316GW61
• Product Range: Procontic b
• Module Category: DCS Control Board / Ethernet Router
• Input Channels: 40
• Output Channels: 24
• Memory Capacity: 1MB
• Power Consumption: 10W
• Weight: 2.24 kg (Shipping Weight) / 0.5 kg (Net Weight)
• Physical Dimensions: 25.0 x 5.3 x 26.5 cm
• Origin: Sweden
• HS Code: 8537101190

Industrial Applications

The HESG216850M1/D 316GW61 is primarily deployed in large-scale DCS infrastructures where synchronization and data integrity are paramount. It is frequently found in petrochemical processing, heavy machinery control, and automated utility grids. Furthermore, its lightweight yet sturdy design allows for flexible installation in various control cabinet configurations. Because it consumes very little power while maintaining high throughput, it represents an efficient solution for facilities aiming to reduce operational overhead without sacrificing control precision.
