The GE DS200GDPAG1AEB serves as a critical power management component within the Mark V Speedtronic control system. This high-frequency board provides regulated power to various GE drives and excitation equipment. It delivers a power rating between 600 and 700 W for stable system operation.
Technical Specifications
| Parameter | Value |
| Brand | General Electric (GE) |
| Model Number | DS200GDPAG1AEB |
| Series | Speedtronic Mark V |
| Input Voltage (AC) | 80 to 132 VAC |
| Input Voltage (DC) | 105 to 140 VDC |
| Power Output | 600 – 700 W |
| Weight | 1.4 kg |
| Dimensions | 28 x 21.4 x 7 cm |
Functional Design and Architecture
The board features a dual-input architecture to support diverse industrial power grids. It integrates an input rectifier and filter stage to clean incoming signals. An internal 27 kHz inverter drives the high-frequency transformation process.
Furthermore, the unit includes specialized protective circuits to prevent hardware damage. Built-in input isolation shields the control logic from voltage spikes and noise. These layers of protection ensure continuous uptime in demanding Distributed Control System (DCS) environments.
