Technical Specifications
| Feature | Details |
| Manufacturer | Foxboro (Schneider Electric) |
| Model Number | FBM217 |
| Part Number | P0914TR |
| Product Type | Discrete Input Module |
| Input Channels | 32 Isolated Channels |
| Supported Voltages | 30V/125V DC, 120V/240V AC (with TAs) |
| Redundancy | Optional Master/Tracker Pair |
| Environmental Class | ISA S71.04 G3 (Harsh) |
| Operating Temp | -20°C to +70°C |
| Physical Dimensions | 4.5 x 11.5 x 11.5 cm |
| Shipping Weight | 0.3 kg |
Flexible Connectivity and Modernization
The FBM217 interfaces with a variety of Termination Assemblies (TAs) to accommodate different voltage levels. These TAs provide essential signal conditioning, such as current limiting and optical isolation. This modular approach allows the FBM217 to support 60V AC, 120V AC, or 240V AC inputs safely. Additionally, this module provides an efficient migration path for older infrastructure. It directly replaces legacy 100 Series hardware, including FBM07, FBM08, and FBM20 modules. This allows plants to upgrade their control capabilities without rewriting entire wiring schemes.
Core Functional Benefits
- High Channel Density: Monitors 32 discrete points in a single compact module slot.
- Redundant Architecture: Supports fail-safe operation for mission-critical monitoring.
- Legacy Compatibility: Simplifies the modernization of older Foxboro DCS installations.
- Rugged Protection: Complies with G3 harsh environment standards for chemical and moisture resistance.
