Schneider Electric BMXDDO3202K Discrete Output Module

The Schneider Electric BMXDDO3202K serves as a high-density 32-channel output solution for the Modicon X80 platform. This module utilizes 24V DC solid-state technology to manage industrial actuators with precision. It features positive logic (source) outputs to ensure compatibility with standard control circuits. Furthermore, the single-slot design maximizes rack space in Modicon M340 and M580 systems. Engineers can deploy this module to coordinate multiple control points within a compact footprint.

Technical Performance and Efficiency

The module operates with a nominal output current of 0.1A per channel. It supports a cumulative current of up to 3.2A per module for heavy-duty requirements. Additionally, the unit exhibits a very low leakage current of less than 0.1mA. This characteristic prevents accidental activation of sensitive field devices. The hardware maintains low power dissipation of only 3.6W during full operation. Consequently, the system reduces heat buildup inside the electrical enclosure.

Reliability and Environmental Compliance

Schneider Electric designed this module to meet EN/IEC 61131-2 standards for industrial equipment. It functions reliably in ambient temperatures ranging from 0°C to 60°C. The solid-state construction eliminates mechanical wear often found in relay-based modules. Therefore, the unit offers a significantly longer service life in high-cycle applications. The compact French-engineered housing also provides excellent resistance to vibration and industrial interference.

Versatile Industrial Applications

The BMXDDO3202K is ideal for automated manufacturing and complex process control. It integrates seamlessly into material handling systems and packaging machinery. The 40-way FCN connector on the front panel simplifies high-density wiring tasks. Moreover, the module provides clear LED diagnostics for rapid troubleshooting on the factory floor. This combination of density and reliability makes it a vital component for modern PLC architectures.

Core Specifications

• Brand: Schneider Electric
• Model: BMXDDO3202K
• I/O Type: Discrete Output
• Channel Count: 32 Channels
• Logic Type: Positive (Source)
• Operating Voltage: 24V DC
• Output Current: 0.1A per channel
• Isolation Resistance: >10 MΩ at 500V DC
• Protection Rating: IP20
• Dimensions: 3.1cm x 10.5cm x 10.3cm
• Weight: 0.12 kg
