Bently Nevada 3500/93 135785-02 Display Unit, backlighted

The Bently Nevada 3500/93 (Part Number 135785-02) serves as the primary local interface for the 3500 Series Machinery Protection System. This backlit display unit provides operators with immediate access to critical machinery data directly at the equipment rack. It displays vital parameters including vibration levels, axial positions, and temperature readings. By utilizing a high-visibility liquid crystal display, the module ensures clear data visualization even in low-light industrial environments.

Core Functionality and Applications

Engineers integrate this display unit into the 3500 rack to facilitate real-time monitoring of Turbo-machinery Instrumentation (TSI). The module connects to the 3500/22M Transient Data Interface to pull system events and current values. It functions as a diagnostic window for plant personnel during startup, steady-state operation, and troubleshooting phases. Common deployment sites include power generation facilities, petrochemical plants, and offshore oil platforms where local status indication remains a safety requirement.

Key Technical Characteristics

The 3500/93 module features a rugged design optimized for long-term industrial service. Unlike standard relay modules, this specific part number focuses on data visualization and system transparency.

• Display Technology: Backlit LCD panel supporting multiple data pages.
• System Compatibility: Designed for seamless integration with 3500/05 racks.
• Operational Range: Maintains performance in temperatures from -30°C to +65°C.
• Data Access: Viewable information includes alarm status, peak hold values, and system OK limits.
• Security: Features password protection to prevent unauthorized configuration changes.
• Mounting Options: Supports face-mount or remote-mount configurations via specialized cables.

Technical Specifications
