Bently Nevada 3500/05-01-02-01-00-01 System Rack

The Bently Nevada 3500/05-01-02-01-00-01 serves as the structural foundation for the 3500 Series Machinery Protection System. This 19-inch rack houses various monitoring modules and power supplies. It facilitates essential communication between components and provides a robust interface for machinery sensors. This specific configuration supports high-availability monitoring in critical industrial environments.

Operational Capabilities

The system rack utilizes a high-speed digital bus for seamless data exchange. It ensures that monitoring modules receive stable power and reliable signal paths. The internal backplane supports up to 14 monitor modules per rack. This design allows for massive scalability in complex plant layouts. Maintenance teams can hot-swap modules without interrupting the operation of other channels.

Industrial Applications

Heavy industries rely on this hardware for Turbine Supervisory Instrumentation (TSI). It excels in power generation, petrochemical processing, and wastewater treatment plants. The rack protects high-speed centrifugal compressors and large induction motors. It also monitors steam turbines and gas expanders in hazardous areas. Its rugged construction withstands the high-vibration environments typical of heavy machinery decks.

Key Performance Benefits

This rack provides the mechanical integrity needed for long-term industrial deployments. It minimizes electrical noise interference through advanced grounding features. The layout simplifies wiring and reduces installation errors during commissioning. It integrates perfectly with System 1 software for comprehensive diagnostic analysis. This hardware ensures your machinery protection system remains active and reliable 24/7.

Technical Specifications

• Rack Size: 19-inch EIA Standard Rack
• Mounting Option: Panel Mount (Front Mounting)
• Backplane Type: Standard Backplane
• Power Supply Option: Single or Dual Bottom-mount
• Agency Approvals: CSA, NRTL/C, CE
• Operating Temperature: -30°C to +65°C
• Weight: 5.95 kg (Empty)
• Physical Dimensions: 482 mm x 266 mm x 249 mm
