Allen-Bradley MIM105-Q6949 80026-096-01 Power Supply

The Allen-Bradley MIM105-Q6949, identified by part number 80026-096-01, is a high-performance switching power supply module specifically engineered for the rigorous demands of industrial automation. This DC/DC converter specializes in transforming a 48VDC input into a regulated 24VDC output, providing a stable energy source for sensitive electronic components. Because industrial environments often face electrical noise and input fluctuations, this module incorporates advanced filtration and regulation circuitry to maintain a consistent 2A current delivery.

Technical Specifications

Key Operational Characteristics

• Precision Voltage Regulation: The module utilizes a switching-mode topology to ensure that the 24VDC output remains within strict tolerances, which effectively protects downstream PLC processors and I/O modules from voltage spikes.
• High-Efficiency Conversion: Through optimized DC/DC conversion logic, the unit minimizes thermal dissipation, allowing it to operate reliably in dense equipment racks without excessive heat buildup.
• Ruggedized Industrial Design: The 80026-096-01 is built to withstand the vibration and electrical interference common in heavy machinery environments, ensuring a long operational lifespan despite harsh conditions.
• Streamlined Integration: Featuring a slender form factor of only 2.5 cm in depth, the power supply fits easily into shallow enclosures or specialized mounting brackets where traditional bulkier supplies would fail.
• Reliable Legacy Support: As a proven Absopulse-based design for Allen-Bradley, this power supply provides the exact electrical characteristics required to keep older automation systems running at peak efficiency.
