Schneider ATV212HU75N4 Variable Speed Drive

The Schneider Electric ATV212HU75N4 delivers optimized motor control for HVAC applications. This 7.5 kW (10 hp) drive specifically regulates three-phase asynchronous motors in ventilation and pumping systems. It operates efficiently within a 380V to 480V AC supply range. Furthermore, the unit features an integrated EMC filter to minimize high-frequency interference. This design ensures compliance with building automation standards for electromagnetic stability. Consequently, the drive provides a reliable solution for modern climate control infrastructures.

Simplified Commissioning and Parameters

Initial setup for the ATV212HU75N4 follows a streamlined and safe procedure. Technicians can configure critical settings by applying power without a run command. The system allows for quick motor frequency resets to 50 Hz or 60 Hz. Additionally, the drive supports precise motor parameter entry to match specific hardware requirements. This flexibility enhances motor protection and maximizes overall drive efficiency. Maintenance teams can easily customize I/O functions to suit various industrial automation demands.

Comprehensive Real-Time Monitoring

The Altivar 212 series includes an intuitive Monitoring mode for operational oversight. Users access this feature by pressing the MODE key until the MON LED lights up. This interface provides immediate visibility for up to 30 distinct data points. Specifically, operators can track output frequency, motor speed, and current levels. This diagnostic depth facilitates rapid troubleshooting and regular performance audits. Therefore, the unit serves as an intelligent node within a facility’s maintenance strategy.

Technical Specifications

Energy Efficiency and System Reliability

This variable speed drive focuses on reducing energy consumption in building management. It utilizes advanced power management to lower the total cost of ownership. Moreover, the compact IP21 housing protects internal components from solid contaminants. The unit handles moderate overloads while maintaining stable speed regulation under fluctuating loads. Its robust architecture supports long-term installation in mechanical rooms and service areas. Choosing the ATV212HU75N4 ensures superior performance for demanding air handling and fluid management tasks.
