ABB DSTD110A 57160001-TZ Digital Output Board

The ABB DSTD110A 57160001-TZ serves as a primary connection unit for industrial digital output management. This terminal board facilitates the distribution of 32 discrete output channels within complex automation environments. It manages electrical signals efficiently while supporting a maximum operating voltage of 60V DC. Because it acts as a centralized interface, the module streamlines the communication between logic controllers and field actuators. Consequently, this hardware provides the essential link required for robust process execution in heavy industries.

Functional Characteristics

This connection unit features a high-density channel layout to minimize cabinet space requirements. It utilizes high-quality contact materials to ensure low signal resistance and long-term durability. Furthermore, the DSTD110A incorporates organized terminal blocks for simplified field wiring and troubleshooting. The board architecture effectively isolates sensitive control electronics from external electrical noise. This design philosophy prevents signal interference from compromising the precision of digital commands. As a result, the module maintains superior operational stability during continuous industrial cycles.

Technical Specifications

• Brand: ABB
• Model Designation: DSTD110A
• Order Number: 57160001-TZ
• Product Category: Digital Output Terminal Board
• Channel Capacity: 32 Channels
• Maximum Voltage: 60V DC
• Net Weight: 1.22 kg
• Physical Dimensions: 24 x 19 x 5.3 cm
• Manufacturing Origin: Sweden
• System Compatibility: Advant Master Process Control

Industrial Application

Engineers typically integrate the 57160001-TZ into Advant Master Process Control Systems for large-scale automation. The board thrives in demanding sectors like chemical processing, power generation, and water treatment. Swedish manufacturing standards ensure the hardware resists mechanical vibration and thermal stress. Additionally, the unit complies with major industrial safety regulations despite being exempt from certain RoHS restrictions. This compliance makes it a reliable choice for maintaining legacy control architectures. Therefore, it remains a cornerstone component for facilities prioritizing uptime and precise output regulation.

Installation and Maintenance

The DSTD110A supports convenient mounting options to accelerate system assembly and commissioning. Its transparent terminal markings reduce the risk of wiring errors during complex installations. Moreover, the board design allows for rapid component testing without disconnecting the entire output loop. This accessibility significantly lowers mean time to repair during critical system maintenance. By providing a clean and accessible wiring interface, the module helps technicians maintain peak system performance. Facilities choose this authentic ABB component to guarantee seamless integration with existing DCS racks.
