Schneider 140DAI55300 Discrete Input Module 100% Brand New In Stock

Schneider 140DAI55300 Discrete Input Module 100% Brand New In Stock

Specifications:

• Range of Product: Modicon Quantum automation platform

• Product or Component Type: VAC discrete input modules

Complementary:

• Software Name: Unity Pro, ProWORX 32, Concept

• Discrete Input Number: 32

• Group of Channels: 4

  Addressing Requirement: 2 input words

• Discrete Input Voltage: 115 V AC

• Input Current:

• 11.1 mA (57...63 Hz)

• 13.2 mA (47...53 Hz)

• Voltage State 1 Guaranteed:

• 79...132 V AC (57...63 Hz)

• 85...132 V AC (47...53 Hz)

• Voltage State 0 Guaranteed:

• 0...20 V AC (57...63 Hz)

• 0...20 V AC (47...53 Hz)

• Input Impedance:

• 12000 Ohm capacitive (57...63 Hz)

• 14400 Ohm capacitive (47...53 Hz)

• Network Frequency Limits: 47…63 Hz

• Maximum Leakage Current: 2.1 mA

• Absolute Maximum Input:

• 132 V continuous

• 156 V for 10 s

• 200 V for 1 cycle

• Response Time:

• 4.9...0.75 ms x line cycle Off-On

• 7.3...12.3 ms On-Off

• Isolation Between Group: 1780 Vrms for 1 minute

• Isolation Between Group and Bus: 1780 Vrms for 1 minute

• Bus Current Requirement: 250 mA

• Maximum Power Dissipation in W: 10.9 W

Local Signalling:

• For bus communication is present (Active): 1 LED (green)

• For external fault detected (F): 1 LED (red)

• For input status: 32 LEDs (green)

Marking: CE

Module Format: Standard

Environment:

• Standards:

• CSA C22.2 No 142

• UL 508

• Product Certifications:

• cUL

• FM Class 1 Division 2

• Resistance to Electrostatic Discharge:

• 4 kV contact IEC 801-2

• 8 kV on air IEC 801-2

• Resistance to Electromagnetic Fields: 9.14 V/m (10 V/m) 80…2000 MHz IEC 801-3

• Ambient Air Temperature for Operation: 32…140 °F (0…60 °C)

• Ambient Air Temperature for Storage: -40…185 °F (-40…85 °C)

• Relative Humidity: 95 % without condensation

• Operating Altitude: <= 16404.2 ft (5000 m)

Packing Units:

• Height: 11.81 in (30.0 cm)

• Width: 1.77 in (4.5 cm)

• Length: 12.28 in (31.2 cm)

• Weight: 15.80 oz (448.0 g)
