GE Fanuc IC200CPUE05 Versatile CPU Module

The GE Fanuc IC200CPUE05 is a versatile CPU module designed for the VersaMax product line. It offers a user-configurable memory of 64KB and embedded communication ports including one RS232, one RS485, and one Ethernet port.

General

• CPU Type: 32-bit RISC

• Memory: 64KB user-configurable

• Communications:

• 1x RS232 port

• 1x RS485 port

• 1x 10Mb Base T Ethernet port

• Operating Temperature: 0 to 55°C (32 to 131°F)

• Storage Temperature: -40 to 85°C (-40 to 185°F)

• Dimensions: 108.5 x 35 x 105.8 mm (4.27 x 1.38 x 4.17 in)

• Weight: 0.45 kg (1 lb)

Performance

• Instruction Execution Time: 160 ns

• Interrupt Response Time: 500 ns

• Ladder Diagram Execution Speed: 0.08 µs/rung

• Function Block Execution Speed: 0.08 µs/instruction

Features

• Supports a wide range of I/O modules

• Easy to program and configure

• Compact and DIN rail mountable

• Built-in diagnostics

• Multi-tasking capabilities

GE Fanuc Products

Description

The IC200CPUE05 is a CPU designed by GE for the VersaMax series. The IC200CPUE05 has a built-in interface, which allows it to serve as the system controller for a maximum of 64 modules with up to 2048 I/O points.

The IC200CPUE05 has two serial ports that are software configured for SNP and RTU slave, Serial I/O operation, and for Local Station Manager operation (Port 1 only). When either port is being used for RTU, an automatic switch to SNP slave mode is required. If the IC200CPUEO5 is in Stop mode and the CPU is configured for Serial I/O, a port will automatically return to SNP slave. Port 2 to can offer power to an external device if power requirement is 100 mA or less at 5VDC. Port 1 is an RS-232 port with a 9-pin female connector. If Port 1 is configured for CPU use, it can be forced by using the Ethernet Restart pushbutton. Port 1 will stay in its current mode until PLC is power cycled or the Ethernet Restart pushbutton has been pressed. Port 2 is an R3-485 port with a female D-sub connector that has 15-pins. The port can be used for program, configuration, and updates and can be attached directly to an RS-485/RS-232 adapter.
