The Bachmann DMS202 is a two-channel, micro controller operated measuring module to read quickly changing strain gauge signals up to approximately 1 kHz with a sample time of only 12.5 µs. It has the following technical specifications:
2 strain gauge measurement inputs
High-quality plug-in connector
2 analog measurement outputs
Automatic measuring range selection (input)
±2/4/8/16mV input range
12bit resolution
25µs sampling time
5 kHz carrier frequency
Isolated
Operating temperature range: -10°C to +70°C
Supply voltage: 24VDC
Power consumption: 1.5W
Here are some technical details about the DMS202:
The DMS202 uses a differential input stage to reduce common mode noise and improve measurement accuracy.
The strain gauge measurement is compensated for temperature and non-linearity.
The DMS202 provides two analog measurement outputs that can be used to connect to a PLC or other control system.
The DMS202 has a built-in filter to reduce noise and improve the signal-to-noise ratio.
The DMS202 is protected against electromagnetic interference (EMI).
| 8310 Power Supply |
| 3008 Main Processor |
| 3503E Discrete Input, 24 V, 32 points |
| 4351B TCM Comm Module with (RJ45) copper |
| 3604E Discrete Output, 24 VDC, 16 points |
| 3601E/3601T Discrete Output, 115 VAC, 16 points |
| 3700A Analog Input, 5 V input, 32 points |
| 3624E Supervised Discrete Output, 24 V, 16 points |
| 3636R Discrete Output (simplx), Relay Cntct, Norm open, |
| 3504E Discrete Input, 24 VDC, 64 points |
| Main Processor Chassis 8110 |
| Expansion Slot Chassis 8111 |
Product Information
² 100% full New! - Original Factory Seal!
² Warranty:12 months in globally
² Package: Original packing with cartons.
² Delivery time: Shipped in 1-3 working days after payment.
