1762-IF2OF2
Allen Bradley
T/T
1 year
| Availability: | |
|---|---|
| Quantity: | |
Description
The 1762-IF2OF2 is an expansion module that is used with Allen-Bradley’s MicroLogix 1100, 1200 and 1400 Programmable Logix Controllers (PLC). This module is a combination analog I/O module that has integrated Four (4) analog channels in total which consists of Two (2) Input and Two (2) outputs, both configurable for Voltage or Current signals.
The module’s input channels support differential input while the outputs are single-ended outputs. Compatible signals for both input and output are 4 to 20 mA for Current while Voltage inputs are 0 to 10V. The full range inputs and outputs are 0 to 10.5Vdc and 0 to 21 mA. Having 12-Bits resolution. The with repeatability of ±0.12%
The module is installed beside the MicroLogix 1100 / 1200 / 1400 compact base. A provided ribbon cable is connected to the adjacent cable to establish the modular bus to provide module interconnection and distribution of bus voltage. It can be installed along the main controller base on a DIN Rail or directly to a mounting plate. Both installation methods require appropriate grounding to eliminate and reduce noise that may affect the device’ operation.
Allen Bradley Main Products:
| 1756-EN2T | 1783-BMS10CGA | 1785-l40c15 | 1746-NO4I |
| 1786-CP | 2711-K10C15L1 | 1746-IA16 | 190E-AND2-CB40S |
| 1788-CNC | 1756-IF4FXOF2F | 1747-BA | 1769-L34ER |
| 1747-L543P | 1766-L32BWA | 1756HP-GPS | 1769-IM12 |
| 1794-IA8 | 2711-B6C8L1 | 1788-CN2FF | 1784-KTX |
| 1757-SRM | 2711P-T12C6B2 | 1772-LW | 1747-OCVGA1 |
Product Information
1. 100% full New! - Original Factory Seal!
2. Warranty:12 months in globally!
3. Package: Original packing with cartons.
4. Delivery time: Shipped in 1-3 days after payment.
